Grade:
Duplex stainless steel :2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc
S22053,S25073,S22253,S31803,S32205,S32304
Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo
Specifications of stainless steel sheet
Standard : ASTM AISI DIN, EN, GB, JIS
Grade:
200 Series: 201,202
300 Series: 301,304,304L,316,316L,316Ti,317L,321,309s,310s
400 Series: 409L,410,410s,420j1,420j2,430,444,441,436
Duplex stainless steel :2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc
S22053,S25073,S22253,S31803,S32205,S32304
Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm
Length :2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 30 mm
Technology : Hot rolled plate (HR), Cold rolled sheet (CR)
Surface Finish : 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Brush, etching, SATIN (Met with Plastic Coated) etc
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats
Application：
It is widely used to make all kinds of container, furnace shell, furnace plate, bridge and automobile static steel plate, low
alloy steel plate, bridge steel plate, made steel plate, boiler steel plate, pressure vessel steel plate, pattern steel plate,
automobile girder steel plate. Some parts and welded components of tractors
| Grade | Other Name | EN Grade | Chemical Component % | |||||||||||
| C | Cr | Ni | Mn | P | S | Mo | Si | Cu | N | W | Other | |||
| 316Ti | 0Cr17Ni12Mo2Ti | 1.4571 | ≤0.08 | 16.00-18.50 | 10.00-14.00 | ≤2.00 | ≤0.045 | ≤0.030 | 2.00-3.00 | ≤0.75 | – | – | – | Ti5(C+N)~0.7 |
| 317 | 0Cr19Ni13Mo3 | ≤0.08 | 18.00-20.00 | 11.00-15.00 | ≤2.00 | ≤0.045 | ≤0.030 | 3.00-4.00 | ≤0.75 | – | 0.1 | – | – | |
| 317L | 00Cr19Ni13Mo3 | 1.4438 | ≤0.03 | 18.00-20.00 | 11.00-15.00 | ≤2.00 | ≤0.045 | ≤0.030 | 3.00-4.00 | ≤0.75 | – | 0.1 | – | – |
| 347 | 0Cr18Ni11Nb | 1.4550 | ≤0.08 | 17.00-19.00 | 9.00-13.00 | ≤2.00 | ≤0.045 | ≤0.030 | – | ≤0.75 | – | – | – | Nb≥10*C%-1.0 |
| 347H | 0Cr18Ni11Nb | 1.4942 | 0.04~0.10 | 17.00-19.00 | 9.00-13.00 | ≤2.00 | ≤0.045 | ≤0.030 | – | ≤0.75 | – | – | Nb≥8*C%-1.0 | |
| 2205 | F51(S31803) | 1.4462 | ≤0.03 | ≥21 | 2.5~3.5 | ≤2 | ≤0.03 | ≤0.02 | ≥2.5 | ≤1 | – | 0.08~0.2 | – | – |
| F60(S32205) | 1.4462 | ≤0.03 | ≥22 | 2.5~3.5 | ≤2 | ≤0.03 | ≤0.02 | ≥3 | ≤1 | – | 0.08~0.2 | – | – | |
| 2507 | F53(S32750) | 1.4410 | ≤0.03 | 24~26 | 6~8 | ≤1.2 | ≤0.035 | ≤0.02 | 3~5 | ≤0.8 | ≤0.5 | 0.24~0.32 | – | – |
| F55 | S32760 | 1.4501 | ≤0.03 | 24~26 | 6~8 | ≤1 | ≤0.03 | ≤0.01 | 3~4 | ≤1 | 0.5~1 | 0.2~0.3 | 0.5~1 | – |
| 329 | S32900 | ≤0.08 | 23~28 | 3~6 | ≤1.5 | ≤0.04 | ≤0.03 | 1~3 | ≤1 | – | – | – | – | |
| A4 | 0Cr17Mn13Mo2N | ≤0.08 | 16.5~18.5 | – | 12~15 | ≤0.045 | ≤0.02 | 1.8~2.2 | ≤0.7 | – | 0.2~0.3 | – | – | |
| TDS2101 | S32101 | 1.4162 | ≤0.04 | 21~22 | 1.35~1.7 | 4~6 | ≤0.04 | ≤0.03 | 0.1~0.8 | ≤1 | 0.1~0.8 | 0.2~0.25 | – | – |
| TDS2003 | S32003 | ≤0.03 | 19.5~22.5 | 3~4 | ≤2 | ≤0.03 | ≤0.02 | 1.5~2 | ≤1 | – | 0.14~0.2 | – | – | |
| S32906 | ≤0.03 | 28~30 | 5.8~7.5 | ≤1.2 | ≤0.03 | ≤0.03 | 1.5~2.6 | ≤1 | ≤0.8 | 0.3~0.4 | – | – | ||
| S32304 | 1.4362 | ≤0.03 | 21.5~24.5 | 3~5.5 | ≤2.5 | ≤0.04 | ≤0.03 | 0.05~0.6 | ≤1 | 0.05~0.6 | 0.05~0.2 | – | – | |
| SUS329J4L | ≤0.03 | 24~26 | 5.5~7.5 | ≤1.5 | ≤0.04 | ≤0.03 | 2.5~3.5 | ≤1 | – | 0.08~0.3 | – | – | ||
| 253MA | UNS S30815 | 1.4835 | 0.05~0.1 | 20~22 | 10~12 | ≤0.8 | ≤0.04 | ≤0.03 | – | 1.4~2 | – | 0.14~0.2 | – | Ce0.03~0.08 |
| 254SMO | UNS S31254 | 1.4547 | ≤0.02 | 19.5~20.5 | 17.5~18.5 | ≤1 | ≤0.03 | ≤0.01 | 6~6.5 | ≤0.8 | 0.5~1 | 0.18~0.22 | – | – |
| AL-6XN | 1.4529 | ≤0.03 | 20~22 | 23.5~25.5 | ≤2 | ≤0.04 | ≤0.03 | 6~7 | ≤1 | ≤0.75 | 0.18~0.25 | – | – | |
| S31050 | 310MOLN | ≤0.02 | 24~26 | 21~23 | ≤2 | ≤0.03 | ≤0.15 | 2~3 | ≤0.4 | – | 0.1~0.16 | – | – | |
| U3 | ≤0.02 | 24~26 | 19~21 | 2.5~3 | ≤0.02 | ≤0.15 | 2.5~3 | ≤0.4 | – | 0.2~0.3 | – | – | ||
| HD | ≤0.03 | 17~19 | 18~20 | ≤1 | ≤0.03 | ≤0.01 | 0.3~0.8 | 4.5~6 | 1.5~2.5 | – | – | – | ||
| C4 | ≤0.03 | 13~15 | 13~15 | ≤1 | ≤0.035 | ≤0.03 | – | 3~4.5 | – | – | – | – | ||
| DS-2 | ≤0.02 | 8~11 | 22~25 | ≤1 | ≤0.03 | ≤0.03 | – | 5~7 | – | – | – | – | ||
| 69111 | 0Cr12Mn5Ni4Mo3Al | ≤0.09 | 11~12 | 4~5 | 4.4~5.3 | ≤0.03 | ≤0.03 | 2.7~3.3 | ≤0.8 | – | – | – | 0.5~1 | |
| s45000 | XM-25 | ≤0.05 | 14~16 | 5~7 | ≤1 | ≤0.03 | ≤0.03 | 0.5~1 | ≤1 | |||||
